320W XL QB V2 R SPEC LED KIT

320W LED V2 R SPEC XL KIT

320 Watt Lamp Kit. High Efficiency QB288 V2 R spec with Samsung LM301H LED. Suited for main light and supplement lighting. 3 ft long heatsink for a wider spread.

Length:891mm, Width:205mm

Dimmable	100-340 Watts
Length	891mm
Width	205mm
Veg Footprint	5×5 sqft
Recommended Flower Footprint	2.5×5 sqft or 2×4 sqft



INCLUDES

• 3x QB288 V2 R spec
• 1x Slate 2 Triple Predrilled 891mm Heatsink
• Meanwell HLG-320H LED Driver. 93.5% Driver Efficiency. Boards should be wired in series with the driver for maximum output
• 6FT Nema 5-15P 16/3 SJTW NA Power Cord or equivalent for standard 120VAC with cable connector
• 2ft solid core Wire, 2x Wago Connectors for DC wiring
• Hanger Clips

Lamp Efficacy with QB 288 V2  2.63 µmol/J
Board Level Efficacy with QB 288 V2 2.75 µmol/J



No Thermal Interface Material is required between the LED board and the heatsink

Remove black plug on driver and use Philips head screw driver for dimming

NOTE: Boards should be wired in series with the driver for maximum output
